Multi Socket PDU
Riello UPS ATS Multi Socket
Riello UPS ATS Multi Socket
Ashdale are delighted to present our range of Riello Uninterruptible Power Supplies to the Northern Ireland market. In Riello we represent a Global UPS company with full local support. We are an officially recognised sales and service partner for Riello UPS. Many systems and accessories in stock in Belfast for immediate dispatch or collection.
Current Range: 16 A
1:1
16 A
Automatic Transfer Switch
The Riello UPS Multi Socket PDU (MDU) is designed to distribute AC power from a single source to 8 outputs with advanced load monitoring and local or remote ON/OFF switching control of individual outlets.
The Riello UPS Multi Socket PDU provides best-in-class power distribution, enabling data center and information technology (IT) managers to effectively monitor and manage their rack environments.
The LCD display allows you to view the status of each output (ON/OFF), the input voltage and current, the current on each output and any alarm codes present.
At the top of the display, there are eight icons representing the status of the eight outputs: if the icon is on, the relative output is powered; if icon is off, the relative output is not powered; if the icon is blinking, the relative output is overloaded.
Expandibility
The Multi Socket PDU is equipped with an expansion slot for accessory communication boards like, for example, network board NetMan 204.
Characteristics
Input current up to 16 A
Maximum output current for a single socket: 4 A
LCD display
Current threshold for outputs settable by user.
Voltage and current threshold for input settable by user
USB and RS232 communication ports.
MDU - INPUT Voltage 184-276 (selectable)
