MGL Non Contact RFID Locking Switches
IDEM solution for non contact safety swtiches.
The MGL range of Non Contact RFID Coded switches has been developed in order to provide and maintain a high level of functional safety whilst providing a reliable magnetic door interlock.
Flexibility for holding force is provided by the provision of 2 different switch sizes - Heavy Duty (1100N Stainless Steel, 1500N Plastic and Die Cast)and Medium Duty (600N Stainless Steel, 1000N Plastic and Die Cast) to cover all applications.Coding is achieved by using magnetic and RFID techniques and both principles need to be satisfied for the switch to operate safely.
The MGL range will connect to the majority of popular standard safety relays to achieve up to PLe/Category 4 to ISO13849-1.Offered in Stainless Steel 316, high specification robust Plastic or Die-Cast Metal housings the MGL switch can be used in almost any environment including high pressure cleaning following contact with foreign particles.The Stainless Steel 316 version has been designed with a Stainless Steel magnet and IP69K rating making it suitable for CIP and SIP processes.
Ashdale are proud to represent IDEM in Northern Ireland.
Our technical team are OEM trained and certified so you can trust us to provide the very best support for sales & service.
If you have an application, please get touch we love solving problems !
MGL-1SS and MGL-2SS
Heavy Duty (1100N) or Medium Duty (600N) holding forces available.
RFID provides a high degree of anti-tamper - virtually impossible to override. Uniquely coded RFID or Series Coded RFID available - depending upon user’s risk assessment for application.
The actuator has been designed to be flexible and therefore has a degree of tolerance to misalignment.
Able to connect to most popular safety relays to achieve up to PLe and Cat.4 for ISO13849-1.
Connect up to 20 switches in series.
Ability to connect other switches and E-Stops in series.
The MGL Stainless Steel 316 model is the perfect solution for food processing, packaging or pharmaceutical applications due to the IP69K rating that allows the switch to undergo high pressure hosing with detergent at high temperature.
Choice of 8-core cable or M12 quick connect (QC).
Remanence magnetization holding technique acts as a light magnetic latch after unlocking.
Supplied with 2 LEDs to indicate all the different switch states.
MGL-1P and MGL-2P
Available with a choice of two holding forces: Heavy Duty (MGL-1P: 1500N) or Medium Duty (MGL-2P: 1000N).
Designed and manufactured in high specification polyester.
RFID provides a high degree of anti-tamper - virtually impossible to override.
Uniquely coded RFID or Series Coded RFID available - depending upon user’s risk assessment for application.
The actuator has been designed to be flexible and therefore has a degree of tolerance to misalignment.
The MGL-1P and 2P are able to connect to most popular safety relays to achieve up to PLe and Cat.4 for ISO13849-1.
Able to connect up to 20 switches in series.
Ability to connect other switches and E-Stops in series.
Unique triggering of solenoid latching mechanism to maintain close control of actuator position.
Choices of 8-core cable or M12 quick connect (QC).
Remanence magnetization holding technique acts as a light magnetic latch after unlocking.
Supplied with 2 LEDs to indicate all the different switch states.
MGL-1M and MGL-2M
Available with a choice of two holding forces, as follows: Heavy Duty (MGL-1M: 1500N) or Medium Duty (MGL-2M: 1000N).
Designed and manufactured with a black die cast aluminium body.
RFID provides a high degree of anti-tamper - virtually impossible to override.
Uniquely coded RFID or Series Coded RFID available - depending upon user’s risk assessment for application.
The actuator has been designed to be flexible and therefore has a degree of tolerance to misalignment.
The MGL-1M and 2M are able to connect to most popular safety relays to achieve up to PLe and Cat.4 for ISO13849-1.
Able to connect up to 20 switches in series.
Ability to connect other switches and E-Stops in series.
Unique triggering of solenoid latching mechanism to maintain close control of actuator position.
Choices of 8-core cable or M12 quick connect (QC).
Remanence magnetization holding technique acts as a light magnetic latch after unlocking.
Supplied with 2 LEDs to indicate all the different switch states.
